126632-01 | Bently Nevada | TMR I/O Module
The Bently Nevada 126648-02 is a precision tmr i/o module for the Bently Nevada 3500 Series machinery protection platform. Type: Triple Modular Redundancy (TMR) I/O Module | System Compatibility: Bently Nevada 3500/42M Proximitor/Seismic Monitoring System | Input Channels: 4 independent channels. Factory-sealed, fully tested on a live 3500 rack with 48-hour burn-in at 55°C. 12-month warranty. Ships within 24 hours from Shenzhen.
Technical Specifications
| 126632-01 | is a TMR I/O module used in the 3500/42M monitoring system. It enables vibration and seismic signal processing for advanced machinery protection. |
|---|---|
| Model | 126632-01 |
| Type | Triple Modular Redundancy (TMR) I/O Module |
| System Compatibility | Bently Nevada 3500/42M Proximitor/Seismic Monitoring System |
| Input Channels | 4 independent channels |
| Supported Sensors | Proximitor and seismic transducers |
| Power Supply | 24V DC |
| Operating Temperature | -40°C to +85°C |
| Dimensions | 155 mm × 136 mm × 119 mm |
| Weight | Approx. 280 grams |
| Environmental Rating | CE & UL industrial compliance |
| Triple Modular Redundancy | Enhances fault tolerance and system uptime |
| Real-Time Signal Processing | Continuous acquisition from vibration and seismic sources |
| High Precision Monitoring | Accurate fault detection and alarm triggering |
| Modular Configuration | Easily integrates into standard 3500 rack systems |
| DCS/SCADA Integration | Compatible with external control platforms |
| Industrial Robustness | Reliable operation in harsh field conditions |
| Plug-and-Play Setup | Quick installation and system scaling |
| Manufacturer | Bently Nevada |
| Model / SKU | 126648-02 |
✓ Ships within 24 hours | ✓ 12-Month Warranty | ✓ Worldwide Delivery
Detailed Product Information
🎯 System Integration
The Bently Nevada 126648-02 connects the 3500 rack to plant condition monitoring and historian infrastructure, streaming real-time vibration and temperature data to System 1, OSIsoft PI, or DCS via Modbus TCP.
Network Options
- Copper (146031-01): 10/100Base-TX, max 100m.
- Fiber (146031-02): 100Base-FX, max 2km — ideal for long runs or high-EMI areas.
Configuration
Static IP mandatory — DHCP expiry causes data gaps. Configure NTP for accurate timestamps. Allow TCP 3500 + TCP 502 through OT firewall.
🔧 Technical Specifications
Specifications
| Parameter | Value |
|---|---|
| 126632-01 | is a TMR I/O module used in the 3500/42M monitoring system. It enables vibration and seismic signal processing for advanced machinery protection. |
| Model | 126632-01 |
| Type | Triple Modular Redundancy (TMR) I/O Module |
| System Compatibility | Bently Nevada 3500/42M Proximitor/Seismic Monitoring System |
| Input Channels | 4 independent channels |
| Supported Sensors | Proximitor and seismic transducers |
| Power Supply | 24V DC |
| Operating Temperature | -40°C to +85°C |
Installation
- Install in assigned rack slot per configuration drawing.
- Copper: CAT5e UTP 100m max. Fiber: 62.5/125μm multimode SC 2km max.
- Assign static IP. Configure NTP. Document settings.
- Verify STATUS LED green and data flowing before returning to service.
📦 Shipping & Warranty
24-hour handling. Anti-static packaging. DHL/FedEx/UPS. 12-month warranty covering port failure, firmware issues, communication dropout.
❓ FAQ
Q: Copper or fiber?
A: Fiber for runs over 100m, high-EMI environments, or electrical isolation requirements. Copper for standard control room under 100m.
Q: Does replacement require reconfiguration?
A: Yes — IP settings are stored on the module. Document your settings before removing the old module.
💰 ROI
The TDI module enables predictive maintenance. One avoided bearing failure on a 50 MW turbine saves $250K-500K. Without it, your 3500 rack is just a trip system.
