1SAP260300R0001 | ABB CD522 S500 Function Module
The ABB 1SAP260300R0001 is a function module for ABB platforms. Extended Product Type: CD522 | Product ID: 1SAP260300R0001 | EAN: 4016779671668. Factory-sealed, live-rack tested, 48-hour burn-in. 12-month warranty. Ships within 24 hours.
Technical Specifications
| CD522 1SAP260300R0001 | is a versatile S500 function module designed for distributed automation I/O applications. It provides encoder inputs, PWM outputs, and configurable digital I/Os, making it ideal for flexible signal processing and control in AC500 PLC systems. |
|---|---|
| Manufacturer | ABB |
| Extended Product Type | CD522 |
| Product ID | 1SAP260300R0001 |
| EAN | 4016779671668 |
| Catalog Description | Function module with 2 encoder inputs, 2 PWM outputs, 2 DI 24VDC, 8 configurable DI/DO 24VDC |
| Product Type | Distributed Automation I/Os |
| Supply Voltage | 24 VDC |
| Output Voltage | 24 VDC |
| Output Current | 2 A |
| Digital Configurable I/Os | 8 |
| Degree of Protection | IP20 |
| Ambient Temperature | Operation 0 … +60 °C; Storage -40 … +70 °C |
| Net Dimensions | 62 mm (depth) × 76 mm (height) × 67.5 mm (width) |
| Net Weight | 0.124 kg |
| Gross Weight | 0.151 kg |
| Package Dimensions | 84 × 72 × 71 mm |
| Customs Tariff Number | 85389091 |
| UNSPSC | 32151705 |
| Flexible I/O Configuration | 8 configurable DI/DO channels for versatile automation needs. |
| Encoder Support | 2 encoder inputs for precise motion and position feedback. |
| PWM Outputs | 2 PWM channels for control of actuators and variable devices. |
| Compact Design | Lightweight and small footprint for easy integration into AC500 PLC systems. |
| Industrial Reliability | Operates in demanding environments with wide temperature range. |
| Compliance | Meets CE, RoHS, and REACH standards for safety and sustainability. |
| Lifecycle Support | Compatible with AC500 V2 CPUs, CM, S500 CI, and S500 IO modules. |
| Model / SKU | 1SAP260300R0001 |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
Why I/O Module Configuration Matters
The ABB 1SAP260300R0001 is an I/O module that handles signal conversion between field devices and the control system. What makes ordering a replacement tricky is that ABB uses configuration codes in their part numbers — the base model might be the same, but suffix codes can change the input voltage range, output type, channel count, isolation rating, or communication protocol. Two modules that look identical from the outside can behave completely differently when plugged into the chassis.
Before ordering, verify the full part number on your existing module label. Do not rely on memory or a handwritten note from the last maintenance shift. Take a clear photo and send it to us if you are unsure — our engineers can cross-reference the part number and confirm compatibility, usually within 4 business hours.
Every I/O module we ship is factory-sealed and functionally tested on a live ABB rack: all channels exercised with calibrated signal sources, communication verified, 48-hour burn-in at 55°C. Printed test report included. 12-month warranty. Worldwide shipping within 24 hours.
