ABB AGBB-01C 68242843 Gate Driver Board in stock
The ABB AGBB-01C is a gate driver board for ABB platforms. Type: Gate Driver Trigger Board | Application: ACS800 inverter modules and drive systems | Operating Voltage: ~30 V DC (driver circuit typical). Factory-sealed, live-rack tested, 48-hour burn-in. 12-month warranty. Ships within 24h.
Technical Specifications
| ABB AGBB-01C (68242843) | is a gate driver trigger board designed for ABB ACS800 series drive modules. It ensures stable gate signal transmission, reliable motor control, and seamless integration into ABB low-voltage AC drive systems. Compact and durable, it is widely used as a service and replacement part in industrial automation. |
|---|---|
| Manufacturer | ABB |
| Type | Gate Driver Trigger Board |
| Application | ACS800 inverter modules and drive systems |
| Operating Voltage | ~30 V DC (driver circuit typical) |
| Trigger Capacity | ~16 A (driver output capability) |
| Signal Input | 4–20 mA (industrial standard) |
| Communication Interface | MODBUS RTU (integration option) |
| Customs Tariff Number | 85049099 |
| Weight | 0.15 kg (net) |
| Mounting | Compact PCB, easy installation in ACS800 modules |
| Reliable Gate Control | Provides stable switching signals for ABB ACS800 drive modules |
| Compact Design | Lightweight and easy to install or replace |
| Durable Construction | Built for long service life in harsh industrial environments |
| Service Support | Official ABB spare part for ACS800 drive maintenance |
| Industrial Compatibility | Seamlessly integrates with ABB control systems |
| ACS800 Drive Systems | Used in inverter modules for precise motor control |
| Industrial Automation | Supports heavy-duty applications in manufacturing, mining, and process industries |
| Maintenance & Repair | Serves as a replacement part for ABB drive service kits |
| Model / SKU | AGBB-01C |
