ABB PM581 1SAP140100R0100 Central Processing Unit
The ABB PM581 is a central processing unit for ABB industrial automation platforms. Product ID: 1SAP140100R0100 | Replacement Product ID (NEW): 1SAP140100R0200 | Type Designation: PM581. Factory-sealed, fully tested, 12-month warranty. Ships within 24 hours.
Technical Specifications
| PM581 | is a |
|---|---|
| Extended Product Type | PM581 |
| Product ID | 1SAP140100R0100 |
| Replacement Product ID (NEW) | 1SAP140100R0200 |
| Type Designation | PM581 |
| EAN | 4016779649322 |
| Catalog Description | PM581 AC500 PLC, 256kB, 24VDC, 2×RS232/485, FBP, SD-Card Slot, LCD Display |
| Customs Tariff Number | 85371091 |
| Dimensions | Width 68 mm, Height 76 mm, Depth/Length 63 mm |
| Net Weight | 0.14 kg |
| Mounting | DIN rail TH35-15 (IEC 60715), horizontal or vertical (with derating) |
| Degree of Protection | IP20 |
| Power Supply | 24 V DC |
| Secondary Current | 0.2 A |
| Display | LCD, 1 line, 8 function keys, 3 LEDs |
| Programming Software | PS501-PROG Control Builder Plus |
| Real-Time Clock | Yes |
| Operating Temperature | 0 … +60 °C |
| Storage Temperature | –40 … +70 °C |
| Max. Operating Altitude | 2000 m |
| RoHS Status | No declaration needed |
| WEEE Category | Not applicable |
| Manufacturer | ABB |
| Model / SKU | PM581 |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
Understanding the ABB PM581
If you maintain ABB systems, you know that not all replacement parts are created equal. The PM581 is a central processing unit engineered specifically for ABB automation platforms. The aftermarket is flooded with modules that look identical on the outside but use inferior components internally. pm581: is a; extended product type: PM581; product id: 1SAP140100R0100; replacement product id (new): 1SAP140100R0200. We have tested clone modules side-by-side with genuine ABB units — the clones typically fail within 3–6 months in continuous industrial service, sometimes taking out the backplane with them.
Every PM581 we sell is 100% genuine ABB, with the manufacturer serial number and holographic label intact. We source from authorized distribution channels and decommissioned system tear-downs with full traceability documentation.
Before inserting this module, power down the chassis completely. ABB modules are generally not hot-swappable. Verify backplane voltage with a calibrated multimeter before insertion. After installation, power up and verify the status LED shows normal operation before returning the system to service. Run the manufacturer diagnostic routine if available.
