ABB | S800 I/O Series | AO815 3BSE052605R1 | Analog Output Module
SKU: AO815 In Stock
ABBAnalog Output ModuleI/O ModuleS800
The ABB AO815 is a analog output module for ABB platforms. Channels: 8 analog output channels | Signal Range: 4–20 mA | Resolution: 12-bit. Factory-sealed, live-rack tested, 48-hour burn-in. 12-month warranty. Ships within 24 hours.
Technical Specifications
| AO815 (Product ID: 3BSE052605R1) | is an |
|---|---|
| Type Designation | AO815 |
| Channels | 8 analog output channels |
| Signal Range | 4–20 mA |
| Resolution | 12-bit |
| Load Resistance (RLmax) | 750 Ω |
| Compatible Termination Units | TU810, TU812, TU814, TU830, TU833 |
| Dimensions | 102 mm (Depth) × 119 mm (Height) × 45 mm (Width) |
| Weight | 0.2 kg |
| Channel Type | AO (Analog Output) |
| Input Channels | 0 |
| Output Channels | 8 |
| HS Code | 853890 |
| Customs Tariff Number | 85389099 |
| RoHS | Compliant with EU Directive 2011/65/EU |
| WEEE Category | 5 (Small Equipment, no external dimension > 50 cm) |
| SCIP Reference | b4fefd01-2c08-458b-a394-de95757d18e0 |
| Number of Batteries | 0 |
| HART Communication | Enables advanced diagnostics and configuration over standard 4–20 mA signals |
| High Accuracy | 12-bit resolution for precise analog output control |
| Compact Design | Lightweight and space-efficient for modular installation |
| System Integration | Compatible with multiple ABB termination units for flexible deployment |
| Industrial Reliability | Engineered for continuous operation in demanding automation environments |
| Manufacturer | ABB |
| Model / SKU | AO815 |
Request a Quote — AO815
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
Category: abb s800 i o seriesactive productsanalog i o modulesfactory newtemp standard tempabb s800abball
Filter by Specification:
Tested Before It Ships
Every ABB AO815 is powered up on a live rack, all channels exercised, communication verified, 48-hour burn-in at 55°C. Printed test report included. Genuine ABB. 12-month warranty. Ships within 24 hours.
