Allen-Bradley 1771-VHSC Very High Speed Counter Module
The Allen-Bradley 1771-VHSC is a very high speed counter module for Allen-Bradley platforms. Maximum Coin Value: 0-999,999 (programmable) | Processing Time: 81W | Processing Time (Worm Case): :. Factory-sealed, live-rack tested, 48-hour burn-in. 12-month warranty. Ships within 24 hours.
Technical Specifications
| Number of Counters | 4 |
|---|---|
| Location | 1771 Series A or B VD chassis |
| Maximum Coin Value | 0-999,999 (programmable) |
| Processing Time | 81W |
| Processing Time (Worm Case) | : |
| Maximum Input Frequency | : |
| Inputs per Counter | 9 (A, B, Gate/reset input) |
| Voltage | 5V or 12-24V (user selectable) |
| Input Current | : |
| Minimum Input Current | 4 mA |
| Number of Outputs | 8 |
| Maximum Output Off-state Leakage Current | Less than 10 μA at 24V DC |
| Maximum On-state Voltage Drop | 0.05Ω per output |
| Output Control | Any number of outputs are assignable to any of 4 counter channels. One 'turn-on' preset value and one 'turn-off' preset per output |
| Output Voltage | 5 to 24V DC, customer supplied |
| Output Current | 2A per channel sourced out. All outputs can be on simultaneously without derating. |
| Output Switching Time | : |
| Filtering | Selectable — high-speed or filtered (filtered < 100Hz) |
| Isolation Voltage | : |
| Power Dissipation | 13 Watts (max); 2 Watts (min) |
| Thermal Dissipation | 54.2 BTU/hr (max); 6.8 BTU/hr (min) |
| Conductors | Bolden 9182 or equivalent Category 211; 750 foot Belden 9182 or equivalent Category 10 |
| Fuse | 7AG 3A fuse — Littelfuse 225003 |
| Environmental Conditions | : |
| Keying Field Wiring Arm Screw Torque | : |
| Manufacturer | Allen-Bradley |
| Model / SKU | 1771-VHSC |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
Why We Test Every Module — Not Just Look at It
In the surplus market, "tested" is a word that gets stretched. We define it clearly for the Allen-Bradley 1771-VHSC: power-up on a live Allen-Bradley rack, all channels exercised with calibrated sources, communication ports verified, 48 hours of continuous operation at 55°C. A printed test report with serial number, test date, and measured values accompanies every shipment. This is what real testing looks like — not a visual inspection, not a "light comes on" check.
Factory-sealed. Genuine Allen-Bradley with full traceability. 12-month warranty. Ships within 24 hours from Shenzhen via DHL, FedEx, or UPS.
