Foxboro | I/A Series | FBM206 P0916GQ | Pulse Input Module
A pulse input module for Foxboro systems — FBM206-P0916GQ handles Field Device Cabling Distance: 22.8 V dc | Loop Power Supply Protection: Each channel is channel-to-channel galvanically isolated, current-limited, and voltage regulated. | Channel Power Supply Input: 24 V dc ±10% at 30 mA maximum to field device.. Factory-sealed, tested on live rack, 48-hour burn-in. Ships today from Shenzhen. 12-month warranty.
Technical Specifications
| FBM206 | 8 isolated independent pulse input channels. |
|---|---|
| Input Pulse Rate | 10 Hz to 25 kHz. |
| Field Device Cabling Distance | 22.8 V dc |
| Loop Power Supply Protection | Each channel is channel-to-channel galvanically isolated, current-limited, and voltage regulated. |
| Channel Power Supply Input | 24 V dc ±10% at 30 mA maximum to field device. |
| Input Voltage Range (Redundant) | 24 V dc +5%, -10% |
| Consumption | 7 W (maximum) |
| Heat Dissipation | 5 W (maximum) |
| Module Temperature | -20 to +70°C (-4 to +158°F) |
| Relative Humidity | 5 to 95% (non-condensing) |
| Altitude | -300 to +12,000 m (-1,000 to +40,000 ft) |
| Temperature | -40 to +70°C (-40 to +158°F) |
| Output Range (Each Channel) | 4 isolated independent 0 to 20.4 mA dc analog output channels. |
| Output Load (Maximum) | 735 Ohms. |
| Compliance Voltage | 18.6 V nominal at 20 mA dc at I/O field terminals. |
| Accuracy | ±0.05% of span (@25°C). |
| Output Temperature Coefficient | 100 ppm/°C. |
| Communication | Via redundant Fieldbus. |
| Settling Time | 100 ms to settle within a 1% band of steady state for a 10 to 90% input step change. |
| Linearity Error | ±0.025% of span (monotonic). |
| Resolution | 12 bits. |
| Manufacturer | Foxboro |
| Model / SKU | FBM206-P0916GQ |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
