GE Fanuc Field Control IC670ALG230 Analog Input Module
Downtime costs thousands per hour. The IC670ALG230 analog input module pays for itself the first time you need it. Current drawn from BIU power supply: 51 mA maximum | Digital Resolution: 12 bits, typical | Analog Resolution: 5.0 microAmps. Factory-new, bench-tested, 12-month warranty.
Technical Specifications
| Input or channel to channel common mode | None; single-ended grouped input |
|---|---|
| Isolation to ground and logic | 1500 VAC for 1 minute, 250 VAC continuous. |
| Current drawn from BIU power supply | 51 mA maximum |
| Digital Resolution | 12 bits, typical |
| Analog Resolution | 5.0 microAmps |
| Input current span | 0.1 mA minimum, 20 mA maximum |
| Input Over-range fault indication | 20.000 mA minimum, 20.500 mA maximum |
| Maximum Input | 30 mA |
| Input Open Wire (4–20mA scaling only) | 2.0 mA typical |
| Input impedance | 249.75 to 250.25 Ohms |
| Conversion time @ 1MHz clock | 60 Microseconds per channel, typical |
| Type | 1st order RC |
| Transition frequency | 160 Hz typical |
| Maximum error at 25 degrees C | +/- 0.05% full scale, 0.1< Input <20 mA |
| Non-linearity | +/- 0.025% of full scale |
| Temperature coefficient | +/- 0.002% of value per degree C, typical; +/- 0.005% of value per degree C, maximum |
| Manufacturer | GE |
| Model / SKU | IC670ALG230 |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
The IC670ALG230: Real-World Reliability
It is always the same story: 2 AM, the control system alarms, and the spare parts cabinet is empty. The GE IC670ALG230 — a analog input module — is the component that failed. Now you are calling suppliers, hoping someone has stock and can ship today.
That is the scenario we built PLC Parts Direct to solve. We stock the IC670ALG230 in our Shenzhen warehouse — physically, not virtually. When you order, our team picks it from the shelf, verifies the serial number against the test report, packs it in anti-static packaging, and hands it to DHL. You get a tracking number, not a processing status that drags on for weeks.
What you are getting: input or channel to channel common mode: None; single-ended grouped input; isolation to ground and logic: 1500 VAC for 1 minute, 250 VAC continuous.; current drawn from biu power supply: 51 mA maximum; digital resolution: 12 bits, typical. Every unit undergoes multi-point functional verification and 48-hour burn-in at 55°C before shipping. A printed test report is included. For pharmaceutical applications where reliability is everything, we recommend keeping one cold spare of each critical module type. The cost of the spare is negligible compared to the cost of unplanned downtime.
