HIMA F6705 2-Fold Analog Output Module in Stock
A 2-fold analog output module for HIMA systems — the F6705 handles Source Mode: ≤ (UQ - 10 V) / 21.2 mA | Sink Mode: Source voltage UQ (sink mode) ≤ 0.2 % (40 µA) at 25 °C, ≤ 0.4 % at 0...+60 °C | Line Length: Maximum 1000 m (watch for burden). Factory-sealed, tested on live rack with 48-hour burn-in. Ships today from Shenzhen. 12-month warranty.
Technical Specifications
| Resolution | 12 bits (4095 steps) |
|---|---|
| Burden RB | ≤ 550 Ohm incl. line resistance to the burden |
| Source Mode | ≤ (UQ - 10 V) / 21.2 mA |
| Sink Mode | Source voltage UQ (sink mode) ≤ 0.2 % (40 µA) at 25 °C, ≤ 0.4 % at 0...+60 °C |
| Line Length | Maximum 1000 m (watch for burden) |
| Electric Strength | 250 V against Analog-GND |
| Basic Status with Plug-in | I ≤ 40 µA |
| Source Voltage UQ (Sink Mode) | 10 ... 30 V |
| Space Requirement | 4 TE |
| Operating Data | 5 V DC: 85 mA, 24 V DC: 130 mA |
| Outputs | 0/4 ... 20 mA |
| Size | 21*15*7cm |
| Weight | 0.25kg |
| Manufacturer | HIMA |
| Model / SKU | F6705 |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
Why the HIMA F6705 Matters for Your Operation
In offshore, every component in your control system has a specific job — and when one fails, the ripple effects can shut down an entire production line. The HIMA F6705 is a 2-fold analog output module that keeps your platform safety systems and subsea control running without interruption.
Here is what this module actually does. resolution: 12 bits (4095 steps); burden rb: ≤ 550 Ohm incl. line resistance to the burden; source mode: ≤ (UQ - 10 V) / 21.2 mA; sink mode: Source voltage UQ (sink mode) ≤ 0.2 % (40 µA) at 25 °C, ≤ 0.4 % at 0...+60 °C. These are not generic specifications — they determine whether this module will work in your specific HIMA system. We have seen too many cases where a maintenance team ordered a replacement only to find it was the wrong revision or configuration. That is why we test every F6705 on a live HIMA rack before shipping — full signal injection across every channel, not just a visual check.
Installation matters too. The most common cause of DOA reports is not a defective module — it is bent backplane pins from forcing a module in at the wrong angle. Take your time lining up the guides. Apply even pressure. If it does not slide in smoothly, stop and check the alignment. Always wear a grounded wrist strap — static discharge from removing a fleece jacket in a dry offshore platform can exceed 15,000 volts, destroying sensitive input protection diodes instantly.
Think about your sparing strategy. A single HIMA F6705 costs a fraction of what one hour of unplanned downtime costs in offshore. We ship replacements within 24 hours from Shenzhen — but even 24 hours is too long if you are losing production. For critical applications, keep one cold spare on your shelf.
