HIMA | HIMatrix | F35 011 | Safety-Related Controller
The HIMA F35 011 is a safety-related controller for HIMA platforms. Mounting: Horizontal on 35 mm DIN rail | Minimum Distances: 20 mm horizontally, 100 mm vertically (keep ventilation slots free) | Power Supply: 24 VDC, -15% ... +20%, power supply unit with safe isolation in accordance with IEC 61131-2 (SELV, PELV). Factory-sealed, live-rack tested, 48-hour burn-in. 12-month warranty. Ships within 24 hours.
Technical Specifications
| Dimensions | 257 mm x 114 mm x 97 mm (W x H x D) |
|---|---|
| Weight | Approximately 1200 g |
| Mounting | Horizontal on 35 mm DIN rail |
| Minimum Distances | 20 mm horizontally, 100 mm vertically (keep ventilation slots free) |
| Power Supply | 24 VDC, -15% ... +20%, power supply unit with safe isolation in accordance with IEC 61131-2 (SELV, PELV) |
| External Fuse | 10 A time-lag 24 (no electrical isolation) |
| Input Level | Configurable Sensor supply LS+ 3 x 20 V / 100 mA - short-circuit-proof |
| Analog Inputs | 8 (unipolar, no electrical isolation) |
| Accuracy Intrinsic Errors | ±0.1% (25 °C), ±0.5% (60 °C) |
| Accuracy Operating Errors | 2% |
| Safety-Related Accuracy | Related to L-0 ... 10 VDC / -0.1 ... 11.5 VDC or 0 ... 20 mA / -0.4 ... 23 mA (at 500 Ω) |
| Nominal Value/Operating Value | 12 bit / 9 bit |
| Transmitter Supply | 8 x 24 V s 46 mA - short-circuit-proof |
| Output Current | 8 (no electrical isolation), 0.5 A (channels 4 and 8: 1 A at 60 °C, 2 A at 50 °C) |
| Counters Inputs | 2 (no electrical isolation) |
| Frequency | 3 (A, B, C), 5 V or 24 V each, 0 ... 100 kHz |
| Type of Protection | IP20 |
| Operating Temperature | 0 ... 60 °C |
| Storage Temperature | -40 °C ... +85 °C |
| Use in Ex-Zone | Ex113 G EEx nA II T4 X |
| Number of Switch Ports | 4 (RJ-45, 10/100 Mbit/s) |
| Number of Fieldbus Interfaces | 3 (see protocol descriptions) |
| Manufacturer | HIMA |
| Model / SKU | F35 011 |
