Honeywell 10005/1/1 Watch Dog Module Genuine and brand new
The Honeywell 10005/1/1 is one of those modules you do not think about until it fails — and then it is all you can think about. Designed as a watch dog module for Honeywell platforms, it manages Function: Watchdog monitoring for FSC | Power Supply: 5 VDC, 175 mA (excluding WDGOUT output) | Input Signals: :. We keep these in physical stock (not virtual inventory) and ship within 24 hours. Each unit includes a printed test report.
Technical Specifications
| 10005/1/1 | is a watchdog module designed for Fail Safe Controller (FSC) systems. It monitors system execution and triggers safe shutdowns in case of faults or hang-ups, ensuring high-integrity control in critical applications. |
|---|---|
| Model Number | 10005/1/1 |
| Function | Watchdog monitoring for FSC |
| Power Supply | 5 VDC, 175 mA (excluding WDGOUT output) |
| Input Signals | : |
| ESD1 | 24 VDC, 5 mA |
| Reset | 24 VDC, 10 mA |
| ESD2 | 5 VDC, 10 mA |
| Max Output Current | 900 mA (5 VDC, protected by 1 A fuse) |
| Communication Interface | S-BUS (Honeywell proprietary) |
| Protection Rating | IP20 |
| Dimensions | 4 TE × 3 HE (approx. 120 × 100 × 50 mm) |
| Weight | 3 kg |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Mounting | Cabinet-mounted, connects to 10005/O/1 or S-BUS |
| 2oo3 Voting Logic | Ensures fault tolerance and safe decision-making |
| Real-Time Monitoring | Detects execution delays or system hang-ups |
| Failsafe Output | De-energizes outputs during emergency shutdown (ESD) events |
| S-BUS Integration | Seamless communication with FSC architecture |
| Robust Design | Built for high-risk environments like oil & gas, chemical, and power sectors |
| Compact Footprint | Space-efficient for dense cabinet installations |
| Global Compliance | Meets international safety and EMC standards |
| Manufacturer | Honeywell |
| Model / SKU | 10005/1/1 |
