Honeywell | C300 System | CC-PDIL01 | Digital Input 24VDC Module

Module: thousands. Downtime in chemical facilities: $10K-$250K/day. One avoided outage = 10-100x ROI. Keep one cold spare.

Deployed in chemical facilities on Honeywell systems.

Examples

• Specification Manufacturer: Honeywell Product Type: CC-PDIL01 24V Digital Input Module Function Accepts 24 VDC signals as discrete inputs Detects open field wires and annunciate bad PV to prevent incorrect control action Provides direct/reverse input indication Optional redundancy Internal or external field power selection On-board excitation power (no need for marshalling power) Supplies non-incendive field power Galvanic isolation IOTA Model Numbers CC-TDIL01 Non-Redundant 9” CC-TDIL11 Redundant 12” CC-GDIL11 Redundant 12” CC-GDIL21 Non-Redundant 6” CC-GDIL01 Redundant for Exp.
• 12” CC-SDXX01 GI-IS I/O Expander 12” Technical Specifications Input Channels: 32 Galvanic Isolation: 1500 VAC RMS or ±1500 VDC Isolation Technique: Optical (in IOM) DI Power Voltage Range: 18–30 VDC ON Sense Voltage / Current: ≥13 VDC or ≥3 mA OFF Sense Voltage / Current: ≤5 VDC or ≤1.
• 2 kΩ Absolute Delay (Input Filter & Isolation): 5 ms ±20% Field Resistance for Guaranteed ON: ≤300 Ω @ 15 VDC Field Resistance for Guaranteed OFF: ≥30 kΩ @ 30 VDC.

No spare = one failure from downtime. Ships within 24 hours.

Handles Honeywell. Honeywell proprietary design.

Specifications

Check: correct slot, backplane power, connector seating, event log. Contact us before RMA — often solved remotely.
