Triconex 3805E Analog Output Modules Brand New
Need a reliable analog output modules for your Triconex system? The 3805E is a factory-sealed unit that handles Number of Points: 8 output | Isolated Points: No, commoned return, DC coupled | Resolution: 12 bits. We test every module on a live rack before it leaves our Shenzhen facility. Ships same day. 12 months warranty.
Technical Specifications
| Type | TMR, AO |
|---|---|
| Output Current Range | 4-20 mA output (+6% overrange) |
| Number of Points | 8 output |
| Isolated Points | No, commoned return, DC coupled |
| Resolution | 12 bits |
| Output Accuracy | <0.25% (in range of 4-20 mA) of FSR (0-21.2 mA), from 32° to 140° F (0° to 60° C) |
| External Loop Power (reverse voltage protected) | +42.5 VDC, maximum; +24 VDC, nominal |
| Over-Range Protection | +42.5 VDC, continuous |
| Switch Time on Leg Failure | < 10 ms, typical |
| Diagnostic Indicators | Module Status (PASS, FAULT, ACTIVE, LOAD, PWR1, PWR2) |
| Color Code | Pea green |
| Manufacturer | Triconex |
| Model / SKU | 3805E |
Ships within 24 hours | 12-Month Warranty | Worldwide Delivery
Understanding the Triconex 3805E
If you maintain Triconex systems, you know that not all replacement parts are created equal. The 3805E is a analog output modules engineered specifically for Triconex automation platforms. The aftermarket is flooded with modules that look identical on the outside but use inferior components internally. type: TMR, AO; output current range: 4-20 mA output (+6% overrange); number of points: 8 output; isolated points: No, commoned return, DC coupled. We have tested clone modules side-by-side with genuine Triconex units — the clones typically fail within 3–6 months in continuous industrial service, sometimes taking out the backplane with them.
Every 3805E we sell is 100% genuine Triconex, with the manufacturer serial number and holographic label intact. We source from authorized distribution channels and decommissioned system tear-downs with full traceability documentation.
Before inserting this module, power down the chassis completely. Triconex modules are generally not hot-swappable. Verify backplane voltage with a calibrated multimeter before insertion. After installation, power up and verify the status LED shows normal operation before returning the system to service. Run the manufacturer diagnostic routine if available.
