Yokogawa AAT145-S00 TC/RTD Input Modules (Isolated Channels)
The Yokogawa AAT145-S00 is a tc/rtd input modules for Yokogawa platforms. Switching Input Signals: TC/mV can be set individually for CH1 to CH16. RTD/POT can be selected individually for CH1 to CH16. | Allowable Input Voltage: ±5 V | Accuracy: ±40 µV for TC, ±150 mΩ for RTD, ±0.2 %/FS for POT. Factory-sealed, live-rack tested, 48-hour burn-in. 12-month warranty. Ships within 24 hours.
Technical Specifications
| Number of Input Channels | 16, isolated channels |
|---|---|
| Span Resistance | 50% or larger of total resistance |
| Switching Input Signals | TC/mV can be set individually for CH1 to CH16. RTD/POT can be selected individually for CH1 to CH16. |
| Allowable Input Voltage | ±5 V |
| Accuracy | ±40 µV for TC, ±150 mΩ for RTD, ±0.2 %/FS for POT |
| Allowable Total Resistance of Signal Source Plus Wiring | 1000 Ω or less |
| Reference Junction Compensation Accuracy | ±1 °C |
| Data Update Period | 1 s |
| Burn-out | All channels can be set together. Detection time: 60 s |
| Temperature Drift | ±80 µV/10 °C for TC, ±0.3 Ω/10 °C for RTD, ±0.4 %/10 °C for POT |
| Maximum Current Consumption | 350 mA (5 V DC) |
| Weight | 0.3 kg |
| External Connection | Dedicated cable (KS1) |
| Manufacturer | Yokogawa |
| Model / SKU | AAT145-S00 |
